Enforcer™ 107’ Ascendant™ Ladder with PUC™ pump
Автор: PierceMfg
Загружено: 2016-04-21
Просмотров: 11170
Описание:
The Ascendant 107’ ladder is available with the exclusive Pierce PUC pump for customers that desire increased compartment space, maneuverability and serviceability. The PUC Ascendant offers two options for ground ladder storage; the standard 115’ or up to 200’ of storage. The PUC pump is available on both the Quint and Texas Chute Out body styles. Truck shown courtesy of Pierce dealership, Siddons-Martin Emergency Group.
Chassis:
• Enforcer chassis
• 70” cab
• Front Axle: TAK-4® independent front suspension, 22,800 lb
• Rear Axle: Meritor RS30-185, 33,500 lb
• GVW Rating: 56,300 lb
• Frame Rails: 10.25”
• Engine: Cummins ISL9, 450 hp, 1250 torque
• Transmission: Allison EVS 3000
• Wheelbase: 234”
• Overall Height: 11’ – 8”
• Overall Length: 39’ – 3”
• 6-person cab seating capacity
• Side Roll and Frontal Impact Protection
• Bumper: 22” painted
• Command Zone™ advanced electronics system
Body and Aerial Device:
• Aluminum body
• Gortite roll-up doors
• Adjustable shelves, 500 Ib capacity
• (4) Storage compartments for air bottles
• Ergonomic crosslay height
• 107’ heavy duty ladder
• 4-section 100k psi steel
• Multi color aerial rung lighting
• Tip Load: 750 lb dry, 500 lb wet
• 1500 gpm flow rate
• 100 lb additional equipment allowance
• Stabilizers: (1) sets of H-style, 18’ spread; (1) Downrigger
• Short-jack spread 13', 12" ground penetration
• Tank: 500 gallons
• Pump: Pierce PUC 1500 gpm, single stage
• Provisions for future Husky™ 3 or Husky 12 foam system
• Tank: 20 gallons
• 10 kW Harrison hydraulic generator
• Pump and roll with two-step shift technology
• Pierce Control Zone™
• Plumbing: Stainless steel
• Valves: Akron 8000 Series
