PANASONIC KX-TES824 ADVANCED HYBRID PABX SYSTEM | HOW TO TERMINATE TELEPHONE CABLES TO RJ11 HEAD

Описание: #PANASONIC #KX-TES824 #ADVANCED #HYBRID #PABX SYSTEM
#PANASONIC #KX-TES824 #ADVANCED #HYBRID #PABX SYSTEM #PIN CONNECTION
#RJ11 PIN TERMINATION

WHAT IS PANASONIC KX-TES824 ADVANCED HYBRID PABX SYSTEM?
=PANASONIC KX-TES824 ADVANCED HYBRID PABX SYSTEM is an
advanced hybrid telephone system. The KX-TES824 is initially configured to 3 exchange lines and 8 extensions. With optional cards you can easily expand the capacity up to 8 exchange lines and 24 extensions. The system comes with built-in DISA / Message on busy, Extension Caller ID, Remote Modem and USB Port for PC Programming.

=============================================================
PANASONIC KX-TES824 ADVANCED HYBRID PABX SYSTEM can be program thru PT or Digital Telephone Set (at the first port of the system) or PC.
IT can be connected also to a DOORPHONE, PAGING, AUTO ATTENDANT (ANSWERING MACHINE), FAX MACHINE, RADIO OR CD PLAYER FOR MUSIC ON HOLD.
=============================================================
TO PROGRAM PANASONIC KX-TES824 ADVANCED HYBRID PABX SYSTEM
1) PRESS PROGRAM
2) PRESS *#
3) PRESS 1234 (default PASSWORD)

=============================================================
RJ11 PIN ASSIGNMENT FOR PT OR DIGITAL EXTENSION, ANALOG EXTENSION, CO LINES
1) FOR PT OR DIGITAL EXTENSION
PIN 2 AND PIN 3 = IST PAIR (TIP/RING)
PIN 1 AND PIN 4 = 2ND PAIR (HIGH/LOW)
============
2) ANALOG EXTENSION
PIN 2 AND PIN 3 = (TIP/RING)
============
2) CO LINES
PIN 2 AND PIN 3 = (TIP/RING)

=============================================================
