Описание: #Vincent #PHO701 Phono Preamplifier Unboxing Exceptional Analog Sound #unboxed

For years, the PHO-700 was Vincent’s best selling phono pre-amplifier. Challenging themselves to improve on the design, Vincent Audio has developed their next stage of phono pre-amplification – the PHO-701.

Using DIP switches on the bottom of the device, it is now possible to make precises adjustments on impedance and capacity. With the PHO-701 you don’t have to compromise and can easily adjust the phono pre-amp to almost any pick-up system. As with the PHO-300 and PHO-500, you can switch between MM and MC at the press of a button. Additionally, Vincent have included a USB port on the PHO 701, allow turntables to be connected to your computer and making it possible to digitise vinyl recordings.

Much like Vincent’s other phono pre-amps the power supply is kept in separate housing, nullifying the power supply’s hum interference and protecting the sound from fluctuations in the public power supply.

Specifications…
Frequency Response: 10 Hz – 20 kHz
Harmonic Distortion: 0.05 % (20 Hz – 20 kHz)
Input Sensitivity: MM: 58 mV, MC: 6.8 mV
Signal-Noise Ratio: MM: 81 dB, MC: 69 dB
Input Impedance: MM: 47k Ohm, MC: 99 – 1000 Ohm (adjustable)
Input Capacity: MM: 15 pF – 350 pF (adjustable), MC: 15 pF
Output Impedance: 250 Ohm
Amplification Factor: MM: 40 dB, MC: 60 dB
Max. Power Consumption: 15 Watt
Inputs: 1 x Stereo RCA
Outputs: 1 x Stereo RCA, USB (24 Bit / 192 kHz)
Tubes: 1 x 12AU7
Colour: Black / Silver
Weight: 2.2 kg
Dimensions (WxHxD): 130 x 95 x 225 mm (for both power supply and PHO-701)
Check out the Newsletter for more information – Vincent PHO-701 Newsletter / Manual / tubeLine Catalog
