Barnes-Munsch Robotics Plastic Extruder Welder Solutions

Описание: Barnes-Munsch Robotics Plastic Extruder Welder Solutions

We offer a purpose built extruder welders for use on robotic arms. The extruders have brushless drives and an external air heater meaning that you can work fast and almost maintenance free.

The extruder would need to be used in conjunction with a Power-Box. The Power-Box contains a frequency converter with EMV-filter and the complete electric for Range of Munsch Extruders with brushless drives. The drive speed of the extruder is adjusted by this Power-Box.

The extruder welders are available in both welding rod or granulate feed.


Key Features:-
Brushless air heater
Brushless drive
Comfortable menu guide with automatic temperature setting
Two materials preset, further spaces for customer`s own programming
Display / Menu
Temperatures can be set digitally
Includes port for checking, adjusting both set and pre-set values and more
Technical Data:-
Maximum welding rate: 7.3 kg/h*
Welding material: PP & PE
Material feed options: Granulate or Welding Rod
Application range: Thicknesses 10 – 50 mm
Weight: Maximum 16.3 Kilos
Electronic speed control: Yes
Extruder heating: 650 / 800 W
Powerbox required: Yes
Preheating: 2300 W**

On Granulate Extruders depending on type and size of the granulate

** Extruder also available without preheating
