Implementing "DOT" Mode to my LM3914 LED Bar Gauge Circuit.
Автор: PKAE Electronics
Загружено: 2026-02-02
Просмотров: 517
Описание:
This is a follow up video to my “Building an LM3914 Alternative LED Bar Gauge Circuit” video. (link below). Following a comment from @d4vidd who asked about implementing dot mode (opposed to bar mode) I have made a simple modification to achieve equivalent effect of an LM3914 configured in dot mode.
My Previous LM3914 Alternative Video:-
• Building an LM3914 Alternative LED Bar Gau...
and, the video which preceded that one:-
• LM3914 Bar/Dot LED Gauge Driver.
If you want to learn more about Op-Amps, see my “All About Op-Amps” video below:-
• All About Op-Amps
You can download a copy of the KiCad Schematics from both videos here:-
https://1drv.ms/f/c/b1fca49f0d60dcca/...
⏱️Timeline
-----------
00:00:00 – Introduction & Demo.
00:00:48 – PKAE Theme.
00:00:58 – Review Schematic (Bar Mode).
00:02:02 – Review Schematic (Dot Mode).
00:05:19 – Bench Testing on Breadboard.
00:05:19 – Wrap Up & Conclusion.
🎶Intro Music from #inaudio :- https://inaudio.org/ Track = OddVision-HYPER POP
