Erica Synths SDIY Polivoks Eurorack VCO - Demo
Автор: synthrotek
Загружено: 2021-09-22
Просмотров: 2630
Описание:
https://store.synthrotek.com/Erica-Sy...
The core of the VCO is borrowed from the famous Russian synth Polivoks VCO and in exponential converter we use the original matched transistor IC that was used in Polivoks.
Features
Triangle, saw and pulse wave outputs
Manually adjustable and CV controlled pulse width
Great tracking across 8 octaves
Exponential FM input with attenuator
Synchronization input
Octave switch – 5 octaves
Skiff-friendly design
We have significantly updated schematics:
Introduced +-10V regulators for greater stability of operation,
Adjusted signal amplitudes to match requirements of contemporary modular synths and made all output signals available simultaneously,
Redesigned CV inputs to accept positive CV signals,
Introduced PWM circuit with manual and voltage controlled pulse width,
Introduced synchronization input, so you can sync the VCO to other VCOs.
