Máy hàn GYS 220 DC 2T/4T/Xung

Описание: MÔ TẢ

Sturdy construction, designed for pipe welding, the TIG 220 DC is a high quality welder for mild and
stainless steels (TIG and MMA). Its ergonomic interface makes settings adjusment easy and intuitive.
OPTIMISED DC WELDING
TIG DC : continuous current for ferrous metals.
TIG DC Pulse : reduces heat distortion of the workpiece.
SPOT : fast and precise spot welding, ideal before welding thin metal sheets.
2 types of start-up : HF (without contact) or LIFT (with contact) forelectro-sensitive environments.
trigger modes : 2T, 4T and 4T LOG.
Automatic detection of the torch : compatible with trigger, double button
and potentiometer torches.
AIP (Adjust Ideal Position) : helps to position the torch before welding
(4T & 4T LOG modes).
MMA WELDING
MMA : Basic rutiles and rutile electrodes (up to Ø 5 mm).
MMA Pulse : Developed for pipe welding as well as vertical upwelding.
STURDY
– Reinforced panels & shockproof rubber pads on the external body.
– Light (12.5 kg), compact and easy to move on-site.
ERGONOMIC INTERFACE
– Displays current/voltage during and after welding (DMOS/QMOS).
– Save 10 programs for each process, for repetitive tasks.
– Food pedal and remote control (optional)
HIGH-TECH POWER SUPPLY
– Flexible Voltage power supply, the machine will work on a single
phase power supply from 85 to 265 V.
– PFC technology (Power Factor Correction), the electrical power
supply usage is optimised for up to 30% energy savings.
WATERCOOLING (optional)
– Flexible Voltage power supply, the machine will work on a single
phase power supply from 85 to 265 V.
– PFC technology (Power Factor Correction), the electrical power
supply usage is optimised for up to 30% energy savings.
WATERCOOLING (optional)
– Automatic, the cooling unit is controlled by the machine.
– Easy connection thanks to the two Plug & Play connectors.
– Water cooled torch, for better comfort and access to difficult areas.
Input power 1 Ph x 230V 50/60Hz
Fuse 16A
Welding current range: I2 TIG 5 – 220A
Welding current range: I2 MMA 10 – 200A
Integ rated technology, A PULSE 0,1 – 90Hz
Dow load cycle (40°C) I2 60%. TIG 165A
Dow load cycle (40°C) X% (I2max)35% TIG 220A
Dow load cycle (40°C) I2 60%. MMA 135A
Dow load cycle (40°C) X% (I2max)25% 200A
Cyele does not load 76V
Rated Power 7 KVA
IP IP 21
Dimensions 42x23x35cm
Weight 12,5 kg
