Monarch Toolroom Lathe, 18.5” x 80” ~ Model 60 ~ Serial No. 32951 in Excellent Condition w/Run demo

Описание: MACHINERY CONSULTANTS INC
BILL WILSON JR. (IN UTAH)
1390 W. 200 S. Salt Lake City, UT 84104
Ph: 801-531-9500 Fx: 801-531-9555
Em: [email protected]
www.machineryconsultants.com

We are pleased to offer, subject to prior sale and our conditions of sale, the following for your consideration:

Pre-Owned Monarch Heavy Duty Toolroom Lathe
18.5” x 80” ~ Model 60 ~ Serial No. 32951 (model 16 x 78)

General Specifications, Approximate
Inventory # MCI STOCK 2022 110
Swing over bed 18.5” actual
Swing over cross slide 10.5”
Max distance between centers 80”
Spindle nose D1-6
Spindle bore 1-5/8”
Spindle speeds (16) 19 to 800 RPM
Tailstock taper #4 MT
Tailstock spindle diameter 3.125”
Tailstock spindle travel 5”
Width of bed 17.5”
Width of Carriage 26.5”
Threads (60) 2 to 120 TPI
Feeds (60) .0017 to .1031 IPR
Main Motor 5 HP 220/440V Note: @ 240 Volts Now
Approx weight 7000 lbs.
Approx dimensions 146”L x 41”W x 69”H

Complete With
• Taper attachment with bed clamp
• Steady rest, w/nylon plugs on spindles, max hole dia. is 4” to 5 ½”
• Monarch OEM Factory follow rest
• Skinner Brand, 12” 3 jaw chuck mounted on it now.
• 10” or 12” 4 jaw chuck (several options to offer in a new import to a used Cushmann)
•
• Aloris brand Wedge type Quick change Tool post Model CA,
to include D40-CA-1 Dorian 1/1/4” Sq. shank cap. / Armstrong USA 31-127

• Removable coolant Chip pan, 2 each
• Coolant System with spigot, hose & pump
• Centers, Live Centers & dead centers
•
• Newall dro as optional item, please inquire.

Condition: This is a Great tool in wonderful condition from long time standby storage!
well tooled, w/ many extras available for this machine, standard tooling)

Inventory # MCI STOCK 2022 110
