Nandland Go Board Project 3 - The Flip-Flop (AKA Register)

Автор: nandland

Загружено: 2016-03-25

Просмотров: 19868

Описание: The third Nandland Go Board Project. Learn about the second most fundamental component inside an FPGA: Flip-Flop (or Register). Flip-Flops allow your FPGA to have a concept of State. They allow the FPGA to know what happened previously in time. Flip-Flops require a digital clock, which I introduce in this video. This project toggles the state of an LED when a button is released.

For the text version of this video: https://www.nandland.com/goboard/regi...

For the Clock Constraints (.SDC File):
https://www.nandland.com/goboard/Go_B...

Support this channel! Buy a Go Board, the best development board for beginners to FPGA:
https://www.nandland.com/goboard/intr...

Like my content? Help me make more at Patreon!
/ nandland
