My First Service! Pioneer SX-650

Описание: Back in March of 2024 someone purchased a receiver that I had restored. Shortly after they received it, they messaged me to let me know how much they were enjoying listening to vinyl with their grandson and that brought me a lot of joy. They then asked if I could work on their Pioneer SX 650 stereo receiver that was having issues with the phono section and all of the lamps were out. I want to start offering more services but my time is limited so I said it might take me a couple of months but I'd love to work on it!

I deep cleaned it, replaced some faulty components, fixed any issues I came across, replaced the lamps, and lubricated the controls. It now runs perfectly and this videos shows how I got it there.

If you'd like me to work on your gear, check out my service info: https://forms.gle/Tk5xAEkGgVdyZ4w4A

Chapters:
00:00 Intro & Background info
00:36 Throwback to opening the box
01:33 First Test
02:49 Exterior cleaning
03:21 Cleaning the faceplate & knobs
04:16 Installing LEDs
06:27 Cleaning the Crackly Controls
08:33 Hearing back from Randy
08:48 Electricity Warning
09:15 Testing Power Supply & Amp Voltages
09:42 Recapping the Phono stage
11:35 Burnishing Ground Connections
11:43 Recapping the Power Supply & Main Amp
13:39 Servicing the Pre Amp
14:35 Final testing of all inputs
15:01 Gluing the Knob Inserts
15:43 Final Assembly & Closing thoughts

••••••••••••••••••••••••••••••••••••••••••••••••••••••••
Hey! My name is Matt and I sure do love stereos! I got into this hobby when I was in high school over a decade ago. I had huuuge speakers in my bedroom and way too many pieces of gear (my mom was worried I would become a hoarder haha). I started repairing stereos for friends a few years back and decided to make videos about it! Now I repair gear for people. If you want to send yours in for repair, head to my repair form: https://forms.gle/Tk5xAEkGgVdyZ4w4A
Some of my favorite brands are Yamaha (CRxx20 series receivers, CA 1010/2010 integrated amps), Harman Kardon (Twin power receivers 430, 630, 730, 930), and Sansui (X0X0 series receivers, AU 717, 919 integrated amps).

Test equipment: (I earn a small commission if you buy from these links)
-Dim bulb tester! I made mine but you can find them on various websites
-Soldering iron Hakko FX 888 https://amzn.to/3JhyNrK
-Hakko FR 301 solder sucker https://amzn.to/4ogUecy
-Main Multimeter (Fluke 87V) https://amzn.to/45dvqJS
-Get the mini grabber leads for it! https://amzn.to/4qpJzxt
-Cheaper multimeter (Fluke 115) https://amzn.to/4o9y0ce
-Oscilloscope Siglent SDS 1104X-E https://amzn.to/43ovYMU
-Function generator Siglent SDG 1032X (There are newer versions out so finding this used online is the best option)
-Capacitor tester Peak Atlas ESR 70 https://amzn.to/3JjBauK (The price here fluctuates, you can usually find them cheaper on other stores)
-Transistor tester Peak Atlas DCA 75 (you can get the cheaper 55 model but it’s not as good so if you can afford it this is the one) https://amzn.to/4oaW6TS
-Hagerman labs IRIAA (Phone or signal generator gets dropped to phono cartridge level) https://hagerman-audio-labs.myshopify...
