Multiblade granite block cutting machine block cutter with double blocks

Описание: If you are interested in our Multiblade granite block cutting machine block cutter with double blocks, please see more at https://www.dafonmachine.com/

This video shows the working process of our machine comprehensively.

Its technical parameters are as follows:
Technical data
main motor power 37-45kw
total motor power 40-48kw
beam size 500*600*7500mm
blade size 1600-2500mm
max vertical stroke 1100mm
max processing length 4000mm
max processing width 2200mm
water consumption 8.5m³/h
machine size and weight 7800*4500*6500mm, 12T

We provide customized products, please contact our sales with detail requirement, we will manufacture the machine accordingly:
Special customization size:
Crossbeam length: 6500-10500mm
Side beam length:4500-8000mm

It also has many features:
The bridge cutting machine is mainly for granite and marble, it adopts multidisc and PLC programmable control and man-machine interface, combined with a super-precision rotary encoder for slicing, uses frequency converter to control left-right feeding and adjusts the speed according to the stone material.

It adopts a hydraulic lifting system and forward-backward slicing adopts high-precision screw nut driving, automatic slicing, main spare parts adopt imported good-quality materials.

The block can be placed on the ground directly, saving the cost of trolley and maintenance.

It is especially suitable for cutting high-value granite and marble block because of high-efficiency cutting rate, high precision slicing, flatness, stability, and easy operation.

Production process:
1.Customer need to prepare two sides foundation first , drawing provided by us
2.Install machine and blades
3.Machine cut
4.take down the slab from block one by one, we can make a mold to support the slab, the machine can cut directly to the end and slab will not fall apart
5.The trolley is optional according to customers’ requirement
