Valve Bag Filling System with Robotic Palletizer for Silica Sand

Описание: This valve bag filling system fills 50 Lb. paper valve bags with different types of silica sand before conveying to a robotic palletizer. Ask a question or get a quote for this type of system here: https://www.tinsleycompany.com/contact/

--Process Description--

An operator places empty craft paper valve bags onto one of the 2 spouts. The valve bag filling system automatically starts to fill the bags. After filling, a bag discharge chair automatically tips and drops the 50 Lb. bags of silica sand onto a heavy-duty discharge conveyor.

Next, bags are conveyed over a check weigher to make sure the bag weights are in spec (not underweight). Then, the bags are conveyed past an ink jet printer, or lot code printing head, that prints a lot code on each bag as it goes by.

Bags travel through a series of conveyors that prepare them for stacking by a robotic palletizer: squaring conveyor, accumulation conveyor, and robot pick conveyor.

A robotic palletizer with a bag tool picks up each bag and stacks them on a pallet. Empty pallets are automatically dispensed into the bag stack zone as needed. After each pallet has been filled, they are conveyed to the end of the packaging line where they are removed from wrapping, storage, and shipping.
