MBS SlideRule Setup - Fix the Model After Import
Автор: Keyack Technology Solutions
Загружено: 2024-01-18
Просмотров: 663
Описание:
This is a great video for MBS SlideRule users learning how to adjust things in the Tekla Structures model after import. It shows common areas where things need to be checked and potentially fixed. It shows the power of knowing how to navigate the model into different perspectives, leverage manual modeling techniques, and use custom components to apply fixes to multiple locations with similar conditions across the model.
Chapters
00:00 - Introduction
01:03 - Add Hardware to Rod Bracing
03:08 - Two Columns in the Same Spot
04:47 - Why I Don't Use the Batch Editor
05:31 - Stretch Multiple Clips at the Same Time
09:16 - Use Filters to Delete Columns
11:51 - Copy Mirror the Column
13:11 - Copy the Columns to Other Bays
14:54 - Fix Rod Bracing Web Doubler Clash
20:30 - Adjust Header to Jamb Clip
23:47 - Create a Custom Component of the Clip
27:37 - Bypass Girts at Corner of Building
33:07 - Top of Jamb to Girt
39:14 - Eave to Rafter Bolts Fix
