Xbox Series X No Power issue - how to fix a dead Xbox Series X by replacing a shorted M86965 Mosfet

Описание: In this video, we show you how to fix an Xbox Series X with a no power issue. This Xbox Series X had a shorted M86965 power mosfet which was causing the APU board to short circuit. This video shows you how to replace the mosfet and return the power to the Xbox Series X.

0:00 Introduction
0:18 Overview of the no power fault
1:28 Testing the power supply
3:28 Finding the short on the boards
5:45 Examining the board for physical issues
8:55 Using a thermal camera to find the shorted M86965 Mosfet
11:40 Replacing the shorted M86965 Mosfet
13:25 Testing the Xbox Series X
14:20 Conclusion
