YX-8000 Closed Mixing Tank

Описание: https://ginhong.com/mixing-tanks-vess...

YX Open Mixing Tank
YX open mixing tank, also called mixing tank, is an open top stainless steel mixer machine for the manufacture of low viscosity liquids and preparations in the cosmetics, pharmaceuticals, food and chemicals industries.

YX Open Mixing Tank: Key Features
Complete process of dissolving, mixing, heating and cooling in one unit
Open type tank with portable covers for easy adding raw materials and cleaning
Working capacity from 50L to 20000L
Suitable for shampoo and preparations below 10,000cps viscosity
Variable speed for agitator
Double jackets for heating and cooling
Different jacket designs available for steam and electric heating
Double temperature probes and controllers for electrical heating in mixer tank
All contact parts are made of SS304/316L and mirror polished
Three or four supporting legs
The specifications of the mixing tank comply with cGMP regulations
Push buttons control panel for easy operation
Power supply of 380V, 50Hz, 3 Phase

Machine Characteristic
Working
capacity (L) Agitator power (kw) Speed (rpm) Homogenizer power (kw) Speed (rpm) Heating Method
200 1.1 0~65 2.2~4 3000 Steam;
Electric Heaters;
Hot Water
300 1.5 0~65 2.2~4 3000
500 2.2 0~65 5.5~7.5 3000
1000 3 0~65 7.5~11 3000
2000 4 0~53 11~15 3000
3000 5.5 0~53 18.5 3000
5000 11 0~42 22 3000
10000 15 0~42 30 3000

General Application
Cosmetics & Toiletries: cream, lotion, wax, mascara, gel, toothpaste;
Pharmaceuticals: ointment, dental composite, syrup, injection;
Food: mayonnaise, dressing, jam, butter, margarine, wasabi;
Chemicals: polyester, synthetic fiber, shoe cream;

Mixer Options
Contra mixing design or other slow agitator and impeller designs available
Extra high-speed disperser or batch homogenizer mounted from top or bottom to help dissolve, disperse, emulsify and homogenize
Closed cover design for sanitary purpose
Cold mixing design is available
Platform for one or more mixing tanks
Delta, Panasonic or Siemens PLC for automation of mixing, dissolving, transferring, heating and cooling etc
Mettler-Toledo load cells
Pressure vessel design for different steam pressure
Spray ball can be equipped to connect to customer’s CIP system
SIP is available upon request
Explosion proof motors and electricals
Different power supply acceptable

If you want to learn more about our YX-8000 Open Mixing Tank , please feel free to contact me.
