Easy Simple High Step Up Current Joule Thief - Powered Up Multiple 8 Volts LED using 1.5 AA Battery
Автор: Neodiy
Загружено: 2016-08-12
Просмотров: 20442
Описание:
#diy #joulethief #simple #circuit #howto #DIY #step #up #current #voltage #easy #diagram #schematic #transistor #transistors #inductor #make #create #build
Very useful Joule Thief circuit to power up multiple array of 8 Volts LED bulb using 1.5 volt AA battery. Instead of using the conventional 2n2222a transistor - this circuit is powered by TIP41C transistor to provide more current .
This circuit is very useful for people who are living in remote area where there are no access to electricity. Cheap China batteries can easily provide good lighting from LEDs.
Component
Toroid transformer
1KOhm resistor
TIP41C NPN Transistor
Breadboard
Jumper cable
Easy simple schematic diagram how to make this joule thief refer to http://howtodosteps.blogspot.my/2016/... -- DIY
how to make simple step up voltage circuit on breadboard
easy step up current circuit diagram
increase low voltage to high voltage using transistor
simplest joule thief to power lot of LED using 1.5v AA batteries
easy diy step up current
micro power joule thief
