Schneeberger Norma 5-Axis Compant CNC Tool & Cutter Grinder m/c

Описание: Visit us at www.automatics.com
General Specifications As Per Brochure (Buyers are responsible for confirming

all details below)

Equipped With:
Fanuc 160i-M CNC Control with integrated SPC
5 axis controllable simultaneously
QUINTO Software
Electrical schematics
Operator's Manuals

Specifications:
Axes:
X-axis: 14.58"
Y-axis: 9.85"
Z-axis: 10.64"
A-axis, work piece holding, free rotation, ISO50, resolution 0,000045, 800

rpm, centre height 210 mm
C-axis, 340, grinding wheel head rotation, direct measuring system,

resolution 0,000045
Grinding head
Version: power swivel
Driving power: 4 kw
Spindle speed: 2000 to 9000 RPM
Spindle taper: 20
Machine table
Length: 35.46"
Width: 10.24"
Voltage: 220 / 440 3 ph 50 /60 hz
Axis Driving power: 0.5 kw
Machine dimensions 1470 W / 2450 / 2170 mm
Estimated weight 4000 KG
