TOR-M2E MISSILE SYSTEM: Russian Tomahawk hunter [HD1080p]

Описание: The Tor missile system is an all-weather low to medium altitude, short-range surface-to-air missile system designed for engaging airplanes, helicopters, cruise missiles, precision guided munitions, unmanned aerial vehicles and short-range ballistic threats (Anti-Munitions). NATO reporting name, SA-15 "Gauntlet".

Tor’s TLAR features a turret with a top mounted target acquisition radar, and frontal tracking radar, with 8 ready to fire missiles stored vertically between the two radars. The target acquisition radar is a F band pulse doppler 3D radar, equipped with a truncated parabolic antenna, and a mechanically, later electronically, scanned in azimuth with a 32 degree sector view, and has an average power output of 1.5 kW, which provides a maximum detection range of 25 km/16 mi. The electronic ‘heart’ of the system is a digital fire control system, which allows detection of up to 48 targets and the tracking of ten at any one time, and integrates IFF functionality; the IFF antenna being mounted above the search radar.

9K332 Tor-M2E features:

Improved fire control radar coverage
Four (4) guidance channels, allowing up to four targets to be engaged simultaneously
Protection against spoofing
The reaction time is around 7 seconds
The system is fully automated.

Ammunition of the Tor-M2 includes 8 missiles 9M331 or 16 missiles 9M338 with increased altitude and range. Tor-M2 missiles have a range of 16 km, maximum altitude of 10 km and maximum speed of 1000 m/s. The system is capable of short-stop firing, which takes 2–3 seconds for the system to go from motion to stationary and firing of the missile.

The Tor-M2E is offered in either wheeled (MZKT-6922 vehicle) or tracked chassis and is equipped with a new digital computer system and all weather optical tracking system. It is currently produced at OJSC Izhevsk Electromechanical plant «Kupol».

"Tor-M2E (9К332МE)" – with a 9А331МE tracked chassis mounting two 9M334 missile modules with four 9М9331 missiles. Crew of 2. The system is fully automated.

"Tor-M2K (9К332МК)" – with a wheeled 9А331МК chassis developed by «MZKT» mounting two 9M334 missile modules, each with four 9М9331 missiles.
