HAGER MSN220 | 20Amp Double Pole 6kA Circuit Breaker
Available at Sparky Direct - Electrical Online Wholesaler
https://www.sparkydirect.com.au/p/HAG...
The Hager MSN220 is a double pole circuit breaker which protects and control circuits against overloads and short-circuits. The MSN220 circuit breaker is rated at 6kA and is suitable for commercial and domestic applications.
Features:
20 Amp
Double Pole
6KA
Circuit Breaker
Number of modules: 2
Rated short circuit breaking capacity: 6 kA
Curve: C
Frequency: 50/60 Hz
Rated insulation voltage: 500 V
Operating temperature: -25 to 60 °C
Electric endurance in number of cycles: 4000
Number of mechanical operations: 20000
Top and bottom screw terminals connection capacity with rigid cable: 1/25 mm²
Top and bottom screw terminals connection capacity with flexible cable: 1/16 mm²
Tightening torque: 2,8Nm
Height of installed product: 83 mm
Width of installed product: 35 mm
Depth of installed product: 70 mm
