Ford F150 (IV-gen P702) 2022 Key Programming Using AVDI and RH850/V850 Programmer

Описание: Hello, friends!

Today I am going to show you how to program keys to a new Ford F150 (IV-gen P702) 2022. The procedure requires reading the BCM data. I am using the ABRITES RH850/V850 Programmer for this purpose.

First, take the BCM out of the vehicle. It can take a bit of time, but do not worry. After taking it out, open it to reveal the PCB. Open the ABRITES RH850/V850 Programmer software, choose the RH850 processor family. Go to Ford BCM and open the Wiring diagram. Follow the instructions on which capacitors to remove and how to solder the CB501 wires. It is a no brainer, but I advise you to take your time and do it carefully.

Start the Reading procedure and save the BCM data. It goes straight to the server and you can use it for the key programming, but I always recommend saving your data for backup purposes.

Now, once you've read the data, put the BCM back together and install it the vehicle. Open the ABRITES Diagnostics for Ford Offline. Go to the Special Functions menu and select Program Smart Key.

Put the key you want to learn in the emergency slot of the vehicle (it is at the bottom of one of the cupholders under a plastic cover). And it is done! You have programmed the key.

This procedure can be used to program keys for the Maverick, Mustang, Mach-e, Transit and other models using the same BCM (equipped with a RH850 processor).

Watch the video and tell me what you think. Like and Share my videos, and Subscribe for more! Ring the bell to get notified for every upload.

Have fun!
