Описание: Note:
If #22 did not work as intended, please type '@' before the coordinate 0.9,0.9.
22. RECTANGLE (Enter) 20,0 (Enter) @ 0.9,0.9 (Enter)

HOW TO MAKE 3D NUT IN AutoCAD

Start Drawing

1. LIMITS (Enter) 0,0 (Enter) 100,100 (Enter)
2. POLYGON (Enter) 6 (Enter) 10,10 (Enter) I (Enter) 11.5 (Enter)
3. Enable "Geometric Center" & "Midpoint" on Object Snap Settings
4. CIRCLE (Enter, click the center and the edge of polygon)
5. CIRCLE (Enter, click the center) D (Enter) 10.2 (Enter)
6. Change Custom Model Views to "SW ISOMETRIC"
7. PRESSPULL (Enter, click inside the polygon, move mouse upward) 10 (Enter x2)
8. EXTRUDE (Enter, select the outer circle, Enter, move upward) 10 (Enter)
9. Change Custom Visual Styles to "CONCEPTUAL"
10. CHAMFEREDGE (Enter) D (Enter) 1.6 (Enter) 1.6
(Enter, select the top outer circle, Enter x2)
11. Use Orbit to view the Bottom (Enter if done)
12. CHAMFEREDGE (Enter) D (Enter) 1.6 (Enter) 1.6
(Enter, select the bottom outer circle, Enter x2)in
13. INTERSECT (Enter, select the 3D objects, Enter)
14. Change Custom Visual Styles to "2D Wireframe"
15. HELIX (Enter, locate at the bottom center, and top center as shown, Enter)
(Select the helix, right click, choose properties)
(Change the turns to 10, close properties, press Esc to deselect)
16. Change Custom Visual Styles to "CONCEPTUAL"
17.CHAMFEREDGE (Enter) D (Enter) 1 (Enter) 1
(Enter, select the top inner circle, Enter x2)
18. Use Orbit to view the Bottom (Enter if done)
19. CHAMFEREDGE (Enter) D (Enter) 1 (Enter) 1
(Enter, select the bottom inner circle, Enter)
20. Change Custom Model Views to "SW ISOMETRIC"
21. Change Custom Visual Styles to "2D Wireframe"
22. RECTANGLE (Enter) 20,0 (Enter) 0.9,0.9 (Enter)
23. LINE (Enter, draw a triangle, Enter)
24. TRIM (Enter, remove 3 sides of the square, Enter)
25. JOIN (Enter, select the triangle, Enter)
26. SWEEP (Enter, select the triangle, Enter, Select the Helix)
27. Change Custom Visual Styles to "CONCEPTUAL"
28. SUBTRACT (Enter, select the nut, Enter, select the helix, Enter)
29. MOVE (Enter, select the nut) 0,0 (Enter) 20,0 (Enter)
30. ERASE (Enter, select the circle and polygon, Enter)

Change Custom Visual Styles to "SHADES OF GRAY"
