TS9800 SERIES JET VALVE
THE FASTEST NON-CONTACT JET DISPENSING SYSTEM
https://info.techcon.com/jet-valves
KEY FEATURES
• Fast dispensing with high-speed piezo actuator
• Micro shot size for small component applications - as small as 0.5 nL
• Quick and easy setup
• Low to high viscosity fluid jetting (up to 2 million cps)
• Localized fluid housing heater
• Fully adjustable parameter settings with a touchscreen interface
APPLICATIONS
• LCDs/OLEDs edge and end sealing
• Die and frame bonding for camera module assembly
• Jetting silicone phosphor in the LED assembly
• Jetting under-fill in microelectronic package applications
• UV adhesive microdots jetting in medical device applications
The new smart jet valve delivers ultra-fast and high-precision dispensing results for a wide range of adhesives and viscosities. The high-speed piezo actuator enables the valve to dispense as fast as 1500 Hz. continuously with up to 2000 Hz maximum burst and produce micro shot as small as 0.5 nL.
TS9800 series jet valve compact size and modular design aid integration into robotic systems. The valve features fully adjustable parameter settings, allowing the operator to change the jetting properties for different fluid types and optimize the process for repeatable dispensing.
Every component of the valve was designed to the highest tolerances and manufactured to the strictest degree of precision ensuring world-class accuracy and repeatability in drop-to-drop dispensing volume.
#JetValve #FluidDispensing #Dispensing
