DEAD MOBILE CHECK STEP-BY-STEP ✅️|DEAD MOBILE KO KAISE CHECK KARE | MOBILE REPAIRING COURSE
Автор: HT LOGIC
Загружено: 2025-07-12
Просмотров: 6694
Описание:
DEAD MOBILE CHECK STEP-BY-STEP ✅️|DEAD MOBILE KO KAISE CHECK KARE | MOBILE REPAIRING COURSE @htlogic
All Mobile Set Dead Solution✅️
PMIC Buck Voltages⚡️Fluctuation
🔧DEAD MOBILE CHECK STEP-BY-STEP ✅️ | Mobile Repair Training Hindi
🧰 Tools Used:
Microscope
Multimeter
DC Power Supply
Rosin
Hot Air Gun
Jumper Wires
Tweezers
etc. Your Requirements
Technical Institute
---
🔍 Step-by-Step Process:
1️⃣ Visual Inspection (Burn marks, corrosion, broken parts)
2️⃣ Battery & Connector Check
3️⃣ Check Charging Path
4️⃣ Check Main Power Line (VBAT → PMIC)
5️⃣ PMIC Output Buck Voltage Test
6️⃣ CPU, eMMC & XO Check
7️⃣ Shorting Test with Rosin + DC Supply
8️⃣ Reball/Replace Faulty Components
---
⚠️ Common Causes of Dead Mobile:
Water damage
Shorted capacitor or IC
Faulty PMIC
eMMC failure
CPU short
यह वीडियो खास तौर पर उपयोगी है:
Mobile Repairing Students
Professional Technicians
जो लोग Mobile Repairing को Career बनाना चाहते हैं
All Mediatek Set Dead Solution
• All Mediatek Set Dead Solution | Dead Mobi...
Samsung A13 Dead solution
• Samsung a13 dead solution | Mobile Repairi...
---
✅ Watch full video and bring your dead phones back to life!
📌 Like, Share, and Subscribe for more professional-level mobile repair tutorials in Hindi.
📞 For Business Inquiries +91 9654219510 / Training Support – Contact: [Your +91 9654219510 WhatsApp/Email [email protected]
📍 Location: [DELHI
#mobilerepairingcourse #deadmobilesolution
#buckvoltage #deadmobilecheckstepbystep
#DeadMobile #MobileRepair #PMIC #MobileNotPoweringOn #ShortFind #MobileRepairHindi #DCpowerSupply #MultimeterTips
🔧 PMIC BUCK Voltage Fluctuation – Causes, Diagnosis & Solution
📌 What is PMIC BUCK? PMIC (Power Management IC) Buck converters are step-down voltage regulators used to supply stable power (like 1.8V, 1.2V, etc.) to mobile phone CPU, RAM, display, etc.
dead mobile check step by step
dead mobile repairing in hindi
dead mobile solution
dead mobile se data kaise nikale
dead mobile ko kaise check kare
dead mobile testing
dead mobile fault finding
dead mobile fault tracing
dead mobile
dead mobile check multimeter
dead mobile repair step by step
mobile repairing course
mobile repairing course in hindi
buck voltage fluctuation
buck voltage up down
buck voltage not stable
buck voltage nahi aa raha hai
buck voltage fluctuation
buck voltage kaise check kare
buck voltage kya hota hai
buck voltage missing
buck voltage fluctuation qualcomm
buck voltage nahi aa raha hai
buck voltage up down problem
buck voltage not stable
buck voltage up down
---
⚠️ Symptoms of BUCK Voltage Fluctuation:
Phone dead or restarting
CPU heating
Display not working
Boot loop
Voltage jumps (e.g., 1.2V → 0.85V → 0V intermittently)
---
🔍 Common Causes:
1. Short Circuit on Output Line
Capacitor, filter coil, or IC drawing excess current.
2. Corrupt or Damaged PMIC
Internal switching fault inside PMIC.
3. Leakage or Partial Short
High resistance short not easily detected with normal continuity.
4. Faulty Load Component
CPU, RAM, eMMC pulling unstable current.
🔥🔥🔥🔥🔥🔥🔥🪄⚙️⚙️⚙️⚙️⚙️✅️
🛠️ How to Diagnose (without thermal cam):
Tools Needed: Multimeter, DC Power Supply, Rosin/IPA, Hot Air Gun (optional)
1. Check Voltage Stability
Power the board with DC Supply.
Probe BUCK lines like VREG_L1, VREG_L2, S1_1P2, etc.
If they fluctuate (e.g., 0.5V → 1.2V → 0V), suspect short or overload.
2. Check Resistance (Multimeter)
Phone OFF, measure resistance between BUCK line and GND.
If below 50–499Ω, investigate that line.
3. Use Rosin (without thermal cam)
Apply Rosin Pcb ( motherboard )suspected area.
Give DC power → observe smoke/evaporation to spot faulty part.
4. Check Line Current on DC Supply
If current spikes then drops, PMIC is restarting → trace short.
---
✅ Solution Steps:
Fault Type Solution
Shorted Cap Remove or replace capacitor
Faulty Coil Replace filter coil
Dead PMIC Reball or Replace PMIC
CPU Short Try low-heat reflow or check for CPU replacement
Software Issue Flash correct firmware or bootloader
🎓🎓🎓🎓🎓🎓💯✅️⚙️
