LVD's Sirius Laser Cutting Machine with CT-L

Описание: MID-LEVEL LASER CUTTING SYSTEM FOR FAST, EFFICIENT SHEET METAL PROCESSING

Efficient processing of parts at optimal speeds and accelerations to
suit the part geometry
Reliable cutting performance at an affordable price-performance ratio
1500 x 3000 mm (5' x 10') work table area
Incorporates automatic shuttle tables
Quick change lens (5" and 7.5")
Capacitive height sensing maintains a constant distance between
the head and the material being processed and adjusts to any
undulations in the plate
Constant beam length system ensures consistent cutting over the
entire cutting area
NC Optimization maximizes machine productivity without operator
intervention by automatically determining the cutting head motion
based on travel distance
Fast cut-to-cut workpiece changeover
High reliability with low maintenance and operation costs
Integrated LVD - Fanuc machine, control, laser source and motor
drive package
Feature enhanced Sirius Plus model offers affordable automation
possibilities

Key Options:
Loading arm
Choice of 2.5 or 4 kW laser sources
CADMAN-L 3D offline software
Sirius Plus includes additional functionality to allow the addition of
automation
Compact Tower (CT) 4, 6 or 10 pallet automated material handling
system (on Sirius 3015 Plus)

Models available:
Sirius 3015
Sirius 3015 Plus
