Tubes Dimension Standard using BWG Thickness

Описание: Tubes Dimension Standard using BWG Thickness

Chapters:
Opening 00:00
Overview 00:25
BWG Thickness 00:41
Tube diameter and thickness standards USC Unit 01:35
Tube diameter and thickness standards SI Unit 02:13
Closing 02:50

Overview
Reference: Birmingham Wire Gauge (BWG), TEMA Standards recommendation
Outside diameter 6.35 - 50.8 mm (0.25 - 2 inches)
Table 1 Birmingham Wire Gauge (BWG) Thickness
Table 2 Combination of diameter and thickness (USC Unit)
Table 3 Combination of diameter and thickness (SI Unit)

Spreadsheet link: http://bit.ly/FNEngineeringFile
