UT Weld Sidewall Crack Signal

Автор: john burke

Загружено: 2020-03-27

Просмотров: 8953

Описание: This video demonstrates the Ultrasonic Testing signal when inspecting a weld with a sidewall crack. Equipment: Olympus EPOCH 1000i UT tester, 60 degree, 4Mhz, 10mm diameter transducer, 0.625" in thick carbon steel plates with single V 30 degree bevel.

I work at Central Piedmont Community College in Charlotte, NC. Please visit our website to explore your NDE training needs.
Central Piedmont Community College NonDestructive Examination Technology Program
https://www.cpcc.edu/programs/nondest...

Central Piedmont Community College NonDestructive Examination Technology Program College Catalog
http://catalog.cpcc.edu/programsofstu...
