HP M525 M575 M630 M651 M680 M725 M775 ADF Document Feeder Kit L2725-60002 L2718A

Описание: In today's printer service instructions, we will be reviewing the ADF maintenance kit replacement for the HP LaserJet M525 M575 M630 M651 M680 M725 M775 ADF Document Feeder Assembly part number L2725-60002 L2718A

The M525 M575 M630 M651 M680 M725 M775 ADF DOCUMENT FEEDER KIT consists of:
1 M525 M575 M630 M651 M680 M725 M775 ADF pickup roller assy PN unknown
1 M525 M575 M630 M651 M680 M725 M775 ADF separation pad CC355-40005

Fits the following HP laser printer models:
HP Color LaserJet Enterprise Flow MFP M680z
HP Color LaserJet Enterprise M651dn
HP Color LaserJet Enterprise M651n
HP Color LaserJet Enterprise M651xh
HP Color LaserJet Enterprise MFP M680dn
HP Color LaserJet Enterprise MFP M680f
HP LaserJet Enterprise 500 Color MFP M575dn
HP LaserJet Enterprise 500 Color MFP M575f
HP LaserJet Enterprise 500 MFP M525f
HP LaserJet Enterprise 700 Color M775dn
HP LaserJet Enterprise 700 Color M775f
HP LaserJet Enterprise 700 Color M775z
HP LaserJet Enterprise 700 Color M775z+
HP LaserJet Enterprise Color Flow MFP M575c
HP LaserJet Enterprise Flow MFP M525C
HP LaserJet Enterprise Flow MFP M630z
HP LaserJet Enterprise MFP M630f
HP LaserJet Enterprise MFP M630h
HP LaserJet Enterprise MFP M725dn
HP LaserJet Enterprise MFP M725f
HP LaserJet Enterprise MFP M725z
HP LaserJet Enterprise MFP M725z+
HP OfficeJet Enterprise Color Flow MFP X585z
HP OfficeJet Enterprise Color MFP X585dn
HP OfficeJet Enterprise Color MFP X585f
HP ScanJet Enterprise 7500
HP ScanJet Enterprise 8500 fn1

HP M525 M575 M630 M651 M680 M725 M775 ADF symptoms that will tell you it is time to replace the ADF kit:
Message on printer control panel “ REPLACE DOCUMENT FEEDER KIT ”
Paper jams at ADF
Feeding noise at ADF

We will be using the M525 as our demo printer today for the installation. The procedure is similar across all the models described. Start by making sure the printer is off and unplugged. Approach the printer from the front and open access door.

Repair Notes
Repair time of fewer than 10 minutes.
Page count reset instructions can be found below the comment area.
It has a recommended 100,000 page yield.
This M525 M575 M630 M651 M680 M725 M775 ADF kit is available in a number of different options on metrofuser.com
HP M525 M575 M630 M651 M680 M725 M775 printer diagrams can be found at metrofuser.com click on the blog.


To clear this message, hit ‘Administration’, then hit ‘Manage Supplies’, then hit ‘Reset Supplies’ then hit ‘New Document Feeder Kit’ then hit ‘Reset.

Thanks for watching! please click like and subscribe. For more valuable how-to videos and instructions visit metrofuser.com. Click on the blog link and search by model.
