High Performance Optimized Roughing in 17 4 PH Stainless Steel Dry | Seco Tools

Описание: Unlike traditional Optimized Roughing strategies with less than 10% stepover, High-Performance Optimized Roughing takes advantage of the larger chip gullets typically associated with 4 flute end mills. This programming strategy coupled the with advanced variable geometry of the Stabilizer 2.0 raises the bar in metal removal rates.

In this video we utilize advanced Optimized Roughing programming strategies with our high performance 4 flute STR430.2 end mill, taking a 50% radial stepover at almost 2 x diameter of the end mill — at a 7.9 cubic inch MMR in PH Stainless Steel.

Learn about the products, cutting data and other technical information you need to thrive in high performance roughing in our Stabilizer 2.0 brochure.
http://niagaracutter.com/literature/U...

Cutting Data:

Stabilizer 2.0 End Mill
STR430.2-0.500-D2-R030.0-Z4 ALTIN
GPN# 03084100
Cat 50 Power Milling Chuck

High-Performance Optimized Roughing
DRY - AIR BLAST
17-4 PH Stainless Steel, H900 44 HRc

Imperial
DIA 0.500 in
RPM 2,292
IPM 35
SFM 300
IPT 0.00375
Ap 0.9 in
Ae 0.25 in – 50% of Dia

Metric
dia 12.7 mm
RPM 2,292
MMPM 889
SMM 86
MMPT 0.095
Ap 22.9 mm
Ae 6.35 mm – 50% of DIA
