How to draw the development of a truncated hexagonal pyramid in engineering drawing.
Question: A regular hexagonal base side length 30mm and height 60mm rests on its base such that two of it's base sides are perpendicular to the V.P. it is truncated by 30° cutting plane on its vertical axis at 35mm mark. Draw the given
👉🏻 Front elevation
👉🏻 Plan
👉🏻 End elevation
👉🏻 True shape
👉🏻 Development of the lateral surface
#bolartech #technicaldrawing #surfacedevelopment
#developmentofsolids #engineeringdrawing #hexagonalpyramid
