Do you Know Which Conductors Need to be Connected During the Insulation Resistance Test?

Описание: In this video we look at the conductors that must be in place and connected before you can correctly carryout the third dead test insulation resistance. I use both a test rig and BS 7671 On-Site Guide to demonstrate how this dead test needs to be carried out to conform with the Wiring Regulations.

Do you link live conductors (line and neutral) together and test them to the protective conductor? The 2 videos links below show you 2 different techniques for linking live conductors together during the insulation resistant test.

🔵 Insulation Resistance Test (Includes Line and Neutral Together to Earth and Between Live Conductors)    • Insulation Resistance Test (Includes Line ...

🔵 Combined Insulation Resistance Test Line and Neutral Together to Earth & Between Live Conductors    • Combined Insulation Resistance Test Line a...

🕐 Time Stamps - Cut to the action 🕕

00:00 - Insulation resistance test
00:25 - Remove all loads
00:43 - Some conductors are missing
01:05 - Test rig
01:23 - Disconnect SPD's
01:33 - RCBO's and an AFDD
01:47 - Electronics
02:37 - Combined neutral and earth
02:42 - Sheath of the supply cable
02:58 - MET
03:35 - On-Site Guide
04:06 - Test sequence
04:37 - Continuity method 1
05:06 - Continuity method 2
05:24 - Stage 1 of the continuity of a ring final circuit
05:35 - Stage 2 of the continuity of a ring final circuit
05:45 - Stage 3 of the continuity of a ring final circuit
05:58 - Insulation resistance test
06:38 - Covers should be on
07:28 - Linking live conductors together to earth
08:11 - Must be connect to the source earth and protective bonding
08:35 - Carrying out the insulation resistance test

Videos are training aids for City and Guilds (C and G) and EAL courses Level 1, 2, 3 plus AM2, AM2S and AM2E.
