Reinforced Concrete Encased Steel Column Detail
Автор: structuraldetails store
Загружено: 2016-08-14
Просмотров: 14473
Описание:
LINK: https://structuraldetails.com/product...
This is a CAD detail drawing for a Reinforced Concrete Encased Steel Column Detail. Composite column with an HEB240 steel profile section encased in reinforced concrete to make a square sized concrete column.
Detail includes cross section and elevation views with column reinforcement bars, stirrups, minimum cover dimensions. Useful detail when designing composite framed structures with steel columns/beams and reinforced concrete slabs and other members. Mainly used to reduce column sizes when required by the architectural design.
