2018: A Dust Collector Odyssey [CNC Router]

Описание: Improved Version Shown Here:    • 2019: The Dust Collector Journey Continues

My journey to make an extremely effective 3D-printed dust collector for my CNC router—and a summary of the previous iterations that didn't really work for me.

Final router design features a circular ring of magnets that let the user easily change orientation in order to avoid hitting fixtures as needed, and easily remove to change bits.

STL files available here: https://github.com/JeremySCook/DustCo...

Will also need 10-24 screws (and tap) as well as 12mm circular rare earth magnets.

Other Inspiration:

Caleb Kraft's—non-view blocking collector:    • CNC Router dust collection that DOESN'T bl...
gibbed—Shapeoko Makita Dust boot: https://www.thingiverse.com/thing:301...
Hackaday-Clear Dust Skirt: https://hackaday.com/2012/03/14/a-bet...

3D-printing controlled by Octoprint, with the print time-lapse sequences controlled by the Octolapse plugin.

Finally, thanks to Ron at Romaxx for pointing out that the exhaust of my router was likely interfering with the clear collector's suction!
