Revit Parametric Isolated Footing Family with Column & PCC | LOD 200–300 | Step-by-Step Tutorial

Описание: In this tutorial, we create a fully parametric isolated footing family in Autodesk Revit, including column and PCC layer, suitable for LOD 200 to LOD 300 BIM workflows.

This step-by-step tutorial covers the complete process of building a parametric structural footing family, controlling dimensions using parameters, locking geometry with reference planes, and making the family flexible for real project use.

We also cover how to convert Type parameters to Instance parameters, allowing each footing to be controlled individually in the project.

Additionally, the video demonstrates:

Creating reference planes
Adding dimensional parameters
Creating extrusion geometry
Aligning and locking elements
Creating column and PCC layers
Assigning subcategories
Adding material parameters
Preparing the family for real project workflows

This family can be used efficiently for structural modeling up to LOD 300 stage, helping improve modeling speed and consistency in BIM projects.

In an upcoming video, we will also cover Material Take-Off (MTO) and Schedule of Quantities (SOQ) using properly assigned materials.

If you found this tutorial helpful, please subscribe to the channel for more BIM and Revit tutorials.
