Two-Tiered Flat Pedalboard Timelapse Video (1)

Описание: A detailed look at our custom pedalboard/rig wiring process with this two-tiered flat board from ‪@VertexEffectsInc‬ and hinged riser to create a second tier. Full rundown/pedal order below. Also, a list of all cabling/connectors used on the board for all you DIY cats out there.

The pedalboard uses a Moog expression pedal to control multiple effects. This is achievable by using the Mission Engineering Expressionator. The Expressionator allows you to toggle between the pedals expression jacks connected to it for control, as well as save presets. The main reason this device was necessary was due to a few of the pedals not having MIDI built in - OR pedals that had MIDI but expression control that wasn't available via MIDI control.

The board is wired in series. The ‪@wampler_pedals‬ Terraform is wired Pre & Post in separate loops for a bit more tonal options. Here is the full pedal order:
Input to Pitchfork
Wah
Volume
PBC Loop 1 - ‪@fender‬ Pelt Fuzz
PBC Loop 2 - Wampler Terraform Pre
PBC Loop 3 - Vertex Dynamic Distortion
PBC Loop 4 - Vertex Boost MK2
PBC Loop 5 - Vertex SSS
PBC Loop 6 - Wampler Terraform Post
PBC Insert Loop (Loop 7) - ‪@sourceaudioeffects‬ Collider
PBC Out (Stereo) - to Left and Right outputs on custom I/O Box
-----------------------------------------------------------------------------------------------
Interested in having a rig wired by BTPA? Check us out - https://btpa.com/Rig-Building/
-----------------------------------------------------------------------------------------------
Connectors used:
Straight TS - https://btpa.com/sps4.html
Angle TS - https://btpa.com/sp400.html
Straight TRS - https://btpa.com/sps6-s
Angled TRS - https://btpa.com/sp550-s.html
Angled MIDI - https://btpa.com/05DL5M.html
Angled DC Power (2.1x5.5mm) - https://btpa.com/mc-1304.html
Locking 1/4" Chassis Connectors.- https://btpa.com/nj3fp6c-bag.html
PowerCON panel connector - https://btpa.com/NAC3MPA-1.html
-----------------------------------------------------------------------------------------------
Cable used:
Instrument - https://btpa.com/CA-0678.html
TRS/Expression - https://btpa.com/CA-0453-8451.html
MIDI - https://btpa.com/ca-1007.html
DC Power - https://btpa.com/ca-0671.html
-----------------------------------------------------------------------------------------------
