Oxted Line Signal Boxes (mainly late 1960s - mid 1970s)

Описание: Oxted Line Signal Boxes (mainly late 1960s - mid 1970s) from Sanderstead down to East Grinstead and to Barcombe Mills. Not all are covered equally but just as I happened to visit. Obviously my old home of Lingfield features highly and I was also rather fond of the peaceful surroundings of Birchden Junction. The ground frame diagrams shown from Lingfield are from the early 1950s. The South one shows when the Down Loop was in situ, which was used for receiving Race Trains until the mid 1960s (not sure of exact date). The North Ground Frame diagram dates from a time when the loading dock in the goods yard was also used for departing Race Trains. It shows starting signals and the appropriate facing point lock for passenger use, together with a protecting catch point within the yard and a spring point to divert anything trying to run out of the headshunt. I do not remember Race Trains departing from the dock (even in my school days but I did not frequent the place so often then as I did in the late sixties) but the spring point remained in use until the yard closed (mid 1970s).
CORRECTIONS: The photographs of Woldingham captioned October 1972 should read October 1970 and Upper Warlingham should read 8.02.1970 (I should learn when it's time to get to bed!!!)
