MOVE PORTABLE IKON MOBILITY SCOOTER INSTRUCTIONAL VIDEO - IK4SEB (BLUE) & IK4SE0 (ORANGE)

Описание: Available now in Australia from your nearest IKON mobility retailer nationwide.

INSTRUCTIONAL VIDEO showing how to assemble and disassemble your new IKON Mobility Move Portable Mobility Scooter.

AVAILABLE in TWO FANTASTIC COLOURS.

Find more info at:
https://ikonmobility.com.au/move-mobi...

Product User Manual
https://ikonmobility.com.au/wp-conten...

New Australia Wide From Redgumbrand in 2023 is the:
MOVE PORTABLE MOBILITY SCOOTER .

FEATURES INCLUDE:
Portable scooter
Pulls apart for transport and storage
Comfortable mid back contoured seat
Full suspension
Padded loop handlebar
Angle adjustable tiller
Width adjustable flip up padded armrests
Removable shopping basket
LED Headlight
Horn
Fingertip operated controls
Forward / Reverse drive settings
Variable speed setting
Battery power indicator
Rear wheel drive
Flat free tyres
Electromagnetic brake
Front nudge bar
Anti tip wheels at rear

WARRANTY
Structural Frame: 5 years
Drive Train Assembly: 18 months
Other Parts: 12 months
XT 20 Amp Hybrid Gel Batteries: 18 months
2 Amp Charger: 18 months

SPECIFICATIONS
Overall: 1080mm (L) x 480mm (W) x 910mm (H)
Overall pulled apart (including part weight):
Front assembly: 940mm (L) x 440mm (W) x 410mm (H) - 19kgs
Rear wheel assembly: 320mm (L) x 490mm (W) x 250mm (H) - 13kgs
Battery pack: 330mm (W) x 230mm (D) x 230mm (H) - 16kgs
Seat (folded down): 460mm (W) x 610mm (D) x 530mm (H) - 11kgs
Basket: 270mm (W) x 210mm (D) x 240mm (H) - 1kg
Seat: 420 - 550mm (W- int.) x 440mm (D) x 330mm / 355mm / 380mm (H)
Armrests: 325mm (L) x 80mm (W) x 230mm (H from seat) - 45°range
Tiller: 410mm (W) x 660mm- varies with angle (H) x 0 - 120° range
Turning Circle: 1400mm
Speed: 6.4km/h
Maximum range: Up to 18km*
Safe climb angle: 6°
Maximum climb angle: 10°
Motor: 270W high torque motor
Batteries: 2 x 24V / 20 Ah (supplied)
Charger: 2 Amp (Supplied)
Tyres (Flat free): Front / Rear: Ø200mm (8”)

Product Weight: 60kg

Maximum User Weight: 130kg (on flat ground)
