LittleMachineShop.com HiTorque 7650 Large Bench Lathe

Описание: The LittleMachineShop.com model 7650 HiTorque 9x20 Deluxe Bench Lathe is the best in its class. It is a significant step up in size, rigidity, and power compared to a mini lathe. This bench top lathe provides a larger bed, more swing over bed, more horsepower, and more rigidity. Compare our standard features and specs to others in this size and price range.

NEW larger spindle through hole - 1.1" (28 mm) accepts 1" stock.
NEW greater swing from 8.5" to 9"
NEW easy-to-read LED display with built in speed readout
NEW factory installed hard-wired DRO on cross slide and carriage

The Deluxe model includes digital readouts (DRO) on the compound rest, cross slide, carriage, and tailstock. Cross slide and carriage DROs feed data from mounted scales to a large display, while compound and tailstock use digital readouts on leadscrews. The DRO system measures in increments .0002" and comes factory installed on the lathe. All DROs read equally accurately in inches and mm.

The Deluxe model also includes an AXA quick change tool post set with five tool holders; anodized aluminum hand wheels; aluminum knobs and levers; and a heavy-duty splash guard that covers the full bed length. In addition, the compound rest is modified to better accommodate the quick-change tool post.

The 1000-Watt brushless spindle drive motor provides tremendous low-end torque. And you can vary the speed from 100 rpm to 2000 rpm continuously in both directions. There are no gears to shift. NSK brand Japanese-quality spindle bearings ensure years of quiet operation.

NEW easy-to-read LED display with built in speed readout allows you to stop and then restart the lathe at a pre-selected speed.

A power cross feed is a feature not found in other lathes of this size. The cross feed and compound rest dials are graduated in 0.001" and advance 0.050" per turn.

A reversible 2 mm pitch lead screw provide extended threading capability. You can create every American Standard Unified class 2A inch screw thread from 6 to 80 threads per inch, and you can create every American Standard Metric class 6h thread from 0.25 to 4 mm pitch with the change gears that are included. All the gears on this lathe are metal.

Features for the model 7650 deluxe lathe:
NEW larger spindle through hole - 1.1" (28 mm) accepts 1" stock.
NEW greater swing from 8.5" to 9"
NEW easy-to-read LED display with built in speed readout
NEW factory installed hard-wired DRO on cross slide and carriage
DRCD digital readout on compound and tailstock
All DROs read equally accurately in inches and mm.
AXA quick change tool post set
1000-Watt output spindle motor with spindle speed display
Genuine NSK bearings
Metal gears
Induction hardened ways
Power longitudinal feed
Power cross feed
E-stop safety power switch
Spindle on-off button
Forward/reverse button for spindle and lead screw direction
Reversible lead screw allows for right- and left-hand threading
Extended threading capability - inch and metric threads
Zero-resettable dials graduated at 0.001" and advancing 0.050" per turn
Cam-lock tailstock
5" (125 mm) 3-jaw self centering lathe chuck

The Bench Lathe comes with the following:
5" (125 mm) 3-jaw self centering lathe chuck with two sets of jaws and a chuck wrench
4-Way rotating tool post
A #4 Morse taper dead center for the headstock
A #2 Morse taper dead center for the tailstock
Change gear set - 18 Gears - 35, 40, 45, 49, 50(x2), 55, 56, 60, 70, 80, 85, 87, 90, 94, 100(x2), 127 teeth
Gears installed on the lathe include 30, 60, 66(x2), 120(x2) teeth
Three open end wrenches: 8/10 mm, 14/17 mm, 17/19 mm
Five hex (Allen) wrenches: 2, 3, 4, 5, 6 mm
Users Manual
Inspection Report

The LittleMachineShop.com model 7600 HiTorque 9x20 Bench Lathe is a version of the SIEG SC50 bench lathe. This lathe does not come with chip tray, but can be ordered separately
