Butterfly CFD | 3d Probes, Units, Turbulence and More | Fluid dynamics Rhino Grasshopper3D | Part 02
Автор: Philipp Galvan Design
Загружено: 2021-04-11
Просмотров: 19894
Описание:
In this video tutorial, we will refine our basic script by adding a legend, understanding fields and units, and that probes can be placed anywhere in the wind tunnel simulation. We distribute probes as point clouds and also try the turbulence models, the first time with the script. Further, we add a Ladybug windrose to get an idea of a real wind situation from real data. Great stuff...
Although there is room for improvement, we are now getting to a functional script that could be used in real projects at least for the early stages in the design process.
General information about Open Foam:
https://www.openfoam.com/
https://openfoam.org/
Rhino3D and Grasshopper3D:
https://www.rhino3d.com/
https://www.grasshopper3d.com/
