Installing a Motorized Latch Retraction (MLR) on our 6300/6400 Exit Device

Описание: Learn how to install PDQ’s Motorized Latch Retraction (MLR) on our 6300 / 6400 Series Exit Devices. This step-by-step guide walks you through the installation process, tools needed, and key tips to ensure a smooth setup.

Chapters:
0:00 – Intro
0:28 – Prepping the exit device for installation
1:02 – Removing your dogging unit (if you have one on your exit device)
1:20 – Unboxing the MLR kit
1:36 – Outlining what comes in the bag of hardware
1:42 – Removing dogging plate and tension screw
1:56 – Mounting the MLR to the push bar assembly
2:47 – Connecting the power wire
2:55 – Putting the push bar assembly back into the rail
3:33 – Tightening tension screws
3:42 – Re-installing filler plate and chassis head cover
3:58 – Conclusion

Helpful Resources:
Download the installation instructions: https://tinyurl.com/446s7bkw
MLR Calibration & Troubleshooting Video Guide:    • Motorized Latch Retraction (MLR) Calibrati...
Learn more about our MLR: https://www.pdqlocks.com/products/mlr...

For additional assistance, please contact our technical support team or visit our website:
P: 717.656.4281
E: [email protected]
W: www.pdqlocks.com
