Andrew LS400 1996-1997 1UZ-FE non VVT-i Plug and Play Adapted from GX110 to IS200

Описание: Here we have an older harness that we originally did in 2019 to be Plug and Play into a GX110. The customer is now fitting the engine into a Lexus IS200 and so we made the changes required to make it Plug and Play into the Lexus IS200.

Video Links to Helpful Videos we have made to assist you when you are installing the Engine Harness

Lexus-Toyota Fuel Systems
   • Lexus/Toyota Fuel Systems How They Work

Toyota-Lexus Mass Air Flow Sensors How to Fit Them
   • Toyota/Lexus Mass Air Flow Sensors How To ...

How to Check your Timing
   • How To Check your Timing on a UZ Engine wi...

Incorrectly Installed or Broken MAF Sensors
   • Toyota Lexus MAF Mass Airflow Sensors. Wha...

1UZ-FE Diagnostic Trouble Shooting
   • 1UZ-FE Diagnostic Trouble Shooting

Toyota/Lexus UZ Engines, The Random Misfire and the Fussy MAF
   • Toyota/Lexus UZ Engines The Random Misfire...

Analogue MPX Converter Coolant Temp Adjustment
   • Analogue MPX Converter Coolant Temp Adjust...

1. Coolant Temp Sensor: 89422-20010
2. Coolant Temp Sensor Gauge: 83420-20040
3. Lambda Sensors: 89465-50120 Denso: DOX-0269
4. 1989-1994 MAF Sensor: 22250-50010
5. 1995-1997 MAF Sensor: 22250-50060
6. Timing Belt: 13568-59045
7. Idler Timing Belt 1: 13505-50022
8. Idler Timing Belt 2: 13503-50011
9. Tensioner Timing Belt: 13540-50011
10. Water Pump: 16100-50022
11. O-Ring Injector 1: 90301-07001
12. Grommet Fuel Injector: 90480-13005
13. Insulator Injector: 23291-41010
14. Gasket Inlet Manifold Middle Section: 17176-50021
15. Gasket Throttle Body: 22271-50010
16. Gasket Inlet Manifold to Cylinder Head: 17171-50011
