1980s Boombox - UPGRADED!

Описание: In this video I show you how I modified a Hitachi TRK-3D80E stereo radio cassette. Modifications include fitting a rechargeable Li-ion battery pack, class D amplifier, better speakers. along with a few other bits. This is already a good boombox and was one of the louder ones of the time. However I wanted to see what is possible with todays parts (purists please look away!). I was trying to do this at a low cost to start with but it did end up costing more than I was expecting, but it was fun to do and I am pleased with the results.

I don't think I'll be carrying it down to the park on my shoulder anytime soon, the upgrades have added an extra 2.6Kg to the weight.
Original weight (with batteries) = 6600g
New upgraded weight = 9217g

Parts used:
XH-M180 Class D amplifier
50000mAh 12volt battery pack (15 x 18650 cells)
12v 5A (60W) switching power supply
Vibe Slick 4 full range speakers
Nubert HDS-135S25PP01 bass speakers
NJM2150BBE 'loudness' board
PT2387 3D Effect Audio Processor IC
XH-A901 Tone Control board
Hi-Link isolated DC-DC power supplies

Additional parts already fitted:
Amazon Echo Dot 2nd generation
NE5532 Op-Amp
BA6317 LED bar graph IC


Links to previous related videos:

Hitachi 3D80 restoration - cleaning and Op-Amp upgrade details
   • 1980s Hitachi boom box restoration - TRK-3D80

Hitachi 3D80 upgrades - Amazon Echo Dot and Stereo LED level meter
   • Retrofit Amazon Echo into 80's boombox


---------------------------------------------------------------------------------------
