Elcon Sawing Technology invented the solution for the cutting-to-size of multi-wall PC panels, the LANCET Cutting Machine.
Please contact your local dealer or visit us at www.elconsawingtechnology.com for more information.
The ELCON Lancet cutting machine, for vertical and horizontal cutting of Multiwall Polycarbonate Sheets with a fixed knife.
Specification of the machine in the video (other dimensions possible):
Cutting height: 2.150 mm
Cutting length: 6.300 mm
Cutting depth: 32 or 50 mm (single panels)
Necessary air pressure: 8 bar
Dimension for horizontal cutting: electronic positioning via Touch-screen
Dimension for vertical cutting: manual positioning with optical scale
Feeding speed: stepless variable up to 60 m/min
Pneumatic plunging cutter knife
Pneumatic tilting cutter knife
Fixed, closed back-side support with felt
Bottom panel support with stainless sliding surface
Pneumatic moving right-hand stop
Pressure beam for vertical cutting
Panel clamps in bottom support
About Elcon Sawing Technology
We are a manufacturer of machines, and have been since 1948. In the 70 years of our existance, we have evolved into the specialist when it comes to processing panels world wide.
Our partners around the world will gladly inform and assist you in finding your perfect machine!
