Introduction to Solid Edge - Part C
Автор: The Design Engineer
Загружено: 2023-07-10
Просмотров: 2002
Описание:
This tutorial video covers essential skills for developing 3D modeling parts by concentrating on sketches using Solid Edge features. Suppose you are new to Solid Edge or in the early stages of learning Solid Edge. In that case, I recommend watching this video and the other introduction videos: Introduction to Solid Edge - Part A & Part B - ( • Introduction to Solid Edge - Part A ) & ( • Introduction to Solid Edge - Part B ). The video covers the following topics:
• Rectangle by center vs. rectangle by two points
• Copy, move, and locate an object at different locations.
• Drawing line curve using three different approaches
• Tangent Circle and Tangent Arc
• Offset, curvature, and curved shapes.
• Moving objects to the Origin (coordinate axes)
Timecodes
00:00 – Intro
02:05 – Rectangle by center vs. rectangle by two points
14:25 – Copy, move, and locate an object at different locations
20:41 – Drawing line curve using three different approaches
27:09 – Offset, curvature, and curved shapes
34:55 – Tangent Circles and Tangent Arc
39:55 – Moving objects to the Origin (coordinate axes)
