Willis 1440E Removable Gap Bed, Engine Lathe with Taper Attachment, New 2 Axis Digital Readout
Автор: Naab Machinery Sales
Загружено: 2021-08-02
Просмотров: 106
Описание:
For Sale Call John 952.836.5784 www.naabmachinery.com
Here We Have:
Willis 1440E Removable Gap Bed, Engine Lathe with Taper Attachment,
New 2 Axis Digital Readout
Serial Number:: 8804025
SPECIFICATIONS:
Swing Over Bed: 14''
Swing Over Carriage: 8.80"
Swing Over Gap 19.80"
Length of Gap: 7.625”
Center Height: 7"
Distance Between Center: 40"
Bed Width: 7.36"
Bed Height: 11.40"
Motor: 3HP
voltage 220v/ 440V Currently Wired 220v 3 Phase
Spindle Bore: 1.60"
Cam Lock Spindle D1-4
Spindle Taper MT#5
Spindle Speeds: 82 - 2000 RPM
Cross Slide Travel: 6.30"
Compound Travel: 2.68"
Leadscrew Diameter: .87"
Feed Rod Diameter: .75"
Imperial Thread: 3-56 T.P.I
Metric thread: 0.4-7.2mm
Longitudinal Feed: 0.052-1.392mm/rev 0.002-0.054"/rev
Cross Feed: 0.014-0.380mm/rev 0.00055-0.015"/rev
Tailstock Quill Diameter: 1.25”
Tailstock Taper: MT#3
Complete With:
New 2 Axis Digital Readout
Taper Attachment
3 Jaw Chuck
4 Jaw Chuck
Steady Rest
Follow Rest
5C Collet Closer
Live Center
Manual and Parts List
Change Gear
Coolant Pump and Plumbing
Removeable Chip Pan
Aloris Type Quick Change Tool Post
