Building an Ultimate Laboratory Variable PSU from a Gaming PC Power Supply

Описание: In today’s video, we’re taking a standard gaming PC power supply and transforming it into a versatile laboratory variable power supply unit. Plus, we’ll show you how to add a feature to charge your phone. This DIY project is perfect for electronics enthusiasts and hobbyists looking for a budget-friendly solution for their lab power needs.


Instructions and all downloadable materials available here:
https://www.instructables.com/Ultimat...


Thanks to LoFi Creators, particularly these songs:

Lakey Inspired - Blue Boi
   • LAKEY INSPIRED - Blue Boi
Lo-fi Type Beat - Rain
   • (FREE) Lo-fi Type Beat - Rain
Purrple Cat - Warm Horizon
   • 🍷 Lofi Chillhop Music (Copyright Free) - "...
Artificial.Music - Faithful Mission
   • Faithful Mission


Video Time Stamps:

0:00 - Intro
0:48 - The "Why?"
1:33 - Adjusting a Boost Module
2:12 - Ply Wood Preparations
3:17 - Front Panel Assembly
4:15 - Preparing PSU
4:45 - Housing Assembly
5:46 - Making Out Unit Smart with ESP8266
6:26 - A Bit Of Fireworks
6:47 - Adding Shunts
7:14 - Attaching side panels
8:00 - Adding Esthetics
8:26 - The Finished Product
8:42 - All Necessary Checks
9:14 - Possible Use Cases


Reused Material:
Gaming PC PSU

3D Printed Material:
Corners
12V USB C Chargers + Oled Screen Holder
Frame Front
Frame Back

Bought Material:

1800W boost converter: https://www.aliexpress.com/item/10050...

10A 100V metering units (x3): https://www.aliexpress.com/item/10050...

50A 100V metering units (x2): https://www.aliexpress.com/item/10050...

Banana connectors male female (x20): https://www.aliexpress.com/item/10050...

Fuse Holders (x12): https://www.aliexpress.com/item/40003...

Fuses: https://www.aliexpress.com/item/10050...

Crocodile Connectors: https://www.aliexpress.com/item/10050...

Plywood 1200 x 600 mm
Carbon fiber Vinyl wrap
M3 Screws
M3 Nuts


Tools Used:

Electric Drill
Dremel 3000
Wood saw
Soldering iron
Heat Gun
3D printer

Gear Used For Filming:
Insta 360 One RS
iPhone 15 Pro MAX
