Why do we need JTAG Boundary Scan

Описание: In the 1980s, the Joint Test Action Group (JTAG) developed a specification for JTAG testing that was standardized in 1990 as the IEEE Std. 1149.1-1990. In 1993 a new revision to the IEEE Std. 1149.1 standard was introduced (titled 1149.1a) and it contained many clarifications, corrections, and enhancements. In 1994, a supplement containing a description of the Boundary-Scan Description Language (BSDL) was added to the standard. Since that time, this standard has been adopted by major electronics companies all over the world. Applications are found in high volume, high-end consumer products, telecommunication products, defense systems, computers, peripherals, and avionics. In fact, due to its economic advantages, some smaller companies that cannot afford expensive in-circuit testers are using JTAG.

The JTAG test architecture provides a means to test interconnects between integrated circuits on a board without using physical test probes. It adds a boundary-scan cell that includes a multiplexer and latches to each pin on the device. Boundary-scan cells in a device can capture data from pin or core logic signals, or force data onto pins. Captured data is serially shifted out and externally compared to the expected results. Forced test data is serially shifted into the boundary-scan cells. All of this is controlled from a serial data path called the scan path or scan chain. Figure 1 depicts the main elements of a JTAG device. By allowing direct access to nets, JTAG eliminates the need for a large number of test vectors, which are normally needed to properly initialize sequential logic. Tens or hundreds of vectors may do the job that had previously required thousands of vectors. Potential benefits realized from the use of JTAG are shorter test times, higher test coverage, increased diagnostic capability and lower capital equipment cost.

For more, please visit: http://www.corelis.com/education/JTAG...

JTAG Boundary-Scan Whitepaper
https://www.corelis.com/whitepapers/r...
