The $3 Pixie Transceiver Kit - Get It Ready For DX On 20m

Описание: Get $5 of NEW USER FREE CREDIT using PCBWay. Full feature custom PCB prototype services, PCB assembly, SMD stencils, CNC / 3D Printing: https://pcbway.com/g/gSv3JS

Get your cheap $3 Pixie transceiver kit ready for DX on the 20m band. Let's see how far you can get with only 500mW of output power and minimal modifications to the original Pixie transceiver kit. I am planning on building a custom Pixie transceiver soon and design a new PCB board as well.

QUICK CORRECTION: The inductor is 0.65uH not 0.65mH.
Also if you are using it on a 20m band vertical antenna, the AM broadcast band are either none, or a lot less stronger than on the EFHW antenna. So I recommend the 20m band vertical antenna.

Check all my other project files that you can order:
https://www.pcbway.com/project/member...

73, YO6DXE

Do you enjoy the content ? Support me trough PayPal or become a Patreon !
  / yo6dxe   / https://paypal.me/yo6dxe

ALL DX EXPLORER LINKS:
https://yo6dxe.com/all-links

BLOG ARTICLE:
https://yo6dxe.com/pixie-transceiver-...

GET THE PIXIE KIT HERE:
https://s.click.aliexpress.com/e/_c4p...

OPTIONAL EXTERNAL AMPLIFIED SPEAKER:
https://s.click.aliexpress.com/e/_c3V...

00:00 Intro
01:40 The Modified Pixie
04:37 First Test
05:12 Sponsor
05:55 Schematic And Modifications
08:50 Tip On Capacitors
10:20 Low Pass Filter Inductor
11:05 Power And Harmonics Suppression Test
13:54 Outro
15:25 Receive Demo
