12.3 Inch 1920*720 LVDS Interface IPS TFT LCD Customized Display

Описание: Hello,everyone! Welcome to Leadtek.
Today, I’d like to introduce one of our customized displays – a 12.3-inch display with a resolution of 1920 by 720, specially developed for automotive CMS (Camera Monitor System) application.

Let me walk you through some of its key features:

1.High Brightness:
The module itself reaches up to 1200 nits, and even after the cover glass is added, it still maintains over 1000 nits. This makes it ideal for outdoor automotive environment where high visibility is essential.

2.AG Surface & Transparent holes:
The cover glass features anti-glare surface treatment, reducing reflections and improving visibility. Additionally, there are three transparent holes at the bottom of the glass to accommodate specific system needs.

3.Enhanced Mounting Design:
The backlight is equipped with screw holders, which provide stronger structural support and make it easier for installation and future maintenance.

4.Polarized sunglasses Compatibility:
With the use of linear polarizer, the display remains clearly visible in portrait mode even when wearing polarized sunglasses.
If your application requires clear visibility in both portrait and landscape mode, we can use circular polarizer to achieve this.

To summarize:
This 12.3-inch automotive display is a fully customized solution, offering optimized performance in brightness, cover glass treatment, mechanical structure, and viewing compatibility.

Thanks for your watching, and feel free to contact us if you want to know more details!
Email: [email protected]
Website: https://www.leadtekdisplay.com

✅LCD Size: TFT 12.3’
✅Module number: LTK123FHCGT17-V3
✅Resolution: 1920 x RGB x 720
✅Panel Type: IPS
✅Number of Colors: 262k
✅Viewing Direction: ALL
✅LCM+CG Luminance (cd/m²): 1000
✅LCM Interface: LVDS
✅Active Area (mm): 292.03(W)×109.51(H)
✅CG+LCM Module Size (mm): 335.5(W)×146(H)×8.89(T)
✅Surface treatment: AG
✅Operating Temperature:-30℃~ +85℃
✅Storage temperature: -40℃~ +90℃
