HuaQing Customize Paint Decoating Machine Introduction

Описание: Place the wheel into the basket, push the basket to the designated area. ( 24" wheels, 4pcs/basket)
将轮毂放入清洗篮中，推至指定上位点 ( 24" 轮毂可装4只/篮)

Mechanical arm lift the basket into the decoating tank (5 tanks in total).
First 3 are Ultrasonic decoating tanks. Last 2 are air-flowed rinsing tanks
机械手臂将自动提升清洗篮至脱漆槽, 共五个清洗槽, 前三槽为超声波脱漆槽， 后两槽为鼓泡漂洗槽

Decoating tanks (1-3) are equipped with ultrasonic and customized paint stripper.
Water cooling system maintains the tank temperature at 18-20°C, to minimize evaporation and odor of stripper.
脱漆槽1/2/3 配置超声波及专用脱漆剂, 以及冷水机保持槽内温度恒温在18-20度, 减少脱漆剂挥发, 无脱漆剂异味

With ultrasonic the paint is peeling off rapidly! Tanks 1/2/3 share a common filter tank, which can be system-set automated based on the number of rims processed or manual filtering. Filter baskets require regular cleaning.
脱漆槽 (1/2/3) 清洗中, 肉眼可见漆层快速脱落，1/2/3共用一个过滤槽，可系统设置自动过滤（按照脱漆轮毂数量设定），也可手动过滤漆渣。漆渣过滤框定期清理即可。

After decoating, wheels enter the clean water air-flowed rinsing tanks(4/5).
Overflow holes help collect paint sludge. Before and After(对比脱漆前后效果）

Current testing result: 30 minutes per basket. No paint residue, no corrosion on wheel surface after this decoating cycle.​
Features:
1.Removable paint thickness: Up to 450μ.
2.Challenging areas: valve/mounting holes, and grooves.
3.Post-decoating wheels are ready for re-painting.

漆层脱落后 轮毂将自动进入清水鼓泡漂洗槽( 4/5 ) 漂洗槽配有溢流孔可统一收集漆渣
漂洗完成,对比脱漆前后效果
目前测试单个清洗篮节拍为30分钟/篮. 脱漆后表面无漆残留, 无腐蚀.
特点:
1.可脱450μ厚度的油漆
2.重点部位气门孔，安装孔，沟槽可轻松处理
3.脱漆后轮毂可以再次进行涂装.
