Anchor bolt fixing details | Installing Steel Girder Concrete Column reinforcements | 3d animation

Описание: Installing a steel girder on a concrete column requires the use of anchor bolts. Anchor bolts serve as the connection points between the steel girder and the concrete column, ensuring that the structure remains secure and stable. Anchor bolts typically consist of a threaded shaft with a flat head or hex head and a nut. The shaft is embedded in the concrete while the head and nut are exposed, allowing them to be attached to the steel girder.

We do 3D & 2D Rebar and steel detailing and will deliver good quality Fab/placing drawing and material takeoff at fair pricing.
